Yamaha VXS3SB asennuskaiutin

Yamaha VXS3SB asennuskaiutin
- SR-Bass -tyyppinen subwoofer
- LF (matalataajuus) - 3,5 tuuman kartio
- Taajuusalue (-10 dB): 65 Hz - 180 Hz
- Monipuolinen subwoofer, yhteensopiva matalan ja korkean impedanssin järjestelmien kanssa

3.5" Dual SR-Bass subwoofer for high and low impedance systems
- Versatile subwoofer compatible with low and high impedance systems
- Sound and size ideally matched to the VXS1ML
- SR-Bass technology delivers solid bass in a compact unit
- Satellite connectors for easy setup
- Dedicated wall/ceiling mount hardware supplied
- Black and white models available
- Paintable enclosures and grilles
- Recommended satellite speakers: VXS1ML

GENERAL SPECIFICATIONS:
Speaker type: SR-Bass type Subwoofer
Frequency range (-10dB): 65Hz-180Hz
Components: LF (Low Frequency) - 3.5" Cone
Power rating:
- NOISE: 20W
- PGM: 40W
- PEAK: 80W
Nominal impedance: 8 Ohm
Satellite impedance: 8 Ohm load per satellite output recommended *1
Transformer taps:
- 100V: 15W, 7.5W, 3.8W
- 70V: 15W, 7.5W, 3.8W, 1.9W
SPL (Sound Pressure Level):
- Sensitivity (1W; 1m on axis): 79dB SPL *3
- Peak (Calculated): 98dB SPL *4
I/O connectors: TERMINAL BLOCKS(4pin) Input: +/-, Loop-thru: +/-, TERMINAL BLOCKS(8pin) Satellite output:+/- (ST1~ST4)
Shape: VXS3S: Rectangular
Cabinet material: VXS3S: ABS
Dimensions:
- Width (W): 322mm (12.7") *5
- Height (H): 162mm (6.4") *5
- Depth (D): 118mm (4.6") *5
Net weight: 2.7kg (6.0 lbs) *5
Certificate: NFPA70, CE, RoHS
