Sennheiser EK 100 G4 vastaanotin

Sennheiser EK 100 G4 vastaanotin

Tehokas kameravastaanotin kevyellä alumiinikotelolla evolution langattomille G4 100P -sarjan järjestelmille. Dokumenttielokuvaan, mobiilijournalismiin ja audiovideosovelluksiin.

- Tehokas kameravastaanotin, joka on helppo asentaa mihin tahansa kameraan
- Erinomainen äänenlaatu ja rakennuslaatu
- Helppokäyttöinen ja nopea asennusaika
- Tehokas ja luotettava langaton tiedonsiirto
- Kantama: jopa 100 metriä / 330 jalkaa
- Jopa 8 tuntia käyttöaikaa


What's in the Box
- EK 100 G4 camera receiver
- 2 AA batteries
- CA 2 camera adapter
- CL 1 3.5 mm jack cable
- CL 100 XLR to 3.5 mm jack adapter cable
- quick guide
- safety guide
- manufacturer declaration sheet

Specifications
Dimensions: Approx. 82 x 64 x 24 mm
Compander: Sennheiser HDX
THD, total harmonic distortion: = 0.9 %
Weight: (incl. batteries) approx. 160 g
Audio output: 3.5 mm jack socket: +12 dBu (mono, unbalanced)
Signal-to-noise ratio: = 110 dBA
Switching bandwidth: up to 42 MHz
Peak deviation: ±48 kHz
Nominal deviation: ±24 kHz
Operating time: Typically 8 h
Modulation: Wideband FM
Power supply: 2 AA batteries, 1.5 V or BA 2015 accupack
Current consumption: at nominal voltage: typ. 180 mA, with receiver switched off: = 25 µA
Adjacent channel rejection: = 65 dB
Intermodulation attenuation: = 65 dB
Powering: 3 V battery / 2.4 V rechargeable battery
Receiving frequency: Max. 1680 receiving frequencies, adjustable in 25 kHz steps, 20 frequency banks, each with up to 12 factory-preset channels, no intermodulation 1 frequency bank with up to 12 programmable channels
RF sensitivity: < 1.6 µV for 52 dBA eff S/N
Squelch: low: 5 dBµV, middle: 15 dBµV, high: 25 dBµV
Temperature Range: -10 °C to +55 °C
Receiver Principle: Adaptive diversity
Blocking: = 70 dB
