Proel Eikon 8 2-tie aktiivikaiutin

Proel Eikon 8 2-tie aktiivikaiutin

Jopa neljän vuoden takuu rekisteröimällä!

Bi-amplified 2-way system
1 "soft-dome tweeter for detailed response and a high-resolution sound
Proprietary integrated elliptical waveguide with accurate directivity control
Long-excursion 8” woofer with lightweight fiber-glass composite cone
Precisely calculated front tuning port for greater low-frequency extension
Multiple audio input connectors for connecting any kind of source
HF adjustment for a flexible control of high frequency response
Sophisticated, carefully designed crossover filters for an improved resolution
High-headroom Class AB 20+70W amplifiers with dual accurate CLIP LIMITER
SPL MAX 109 dB
Frequency response 45 Hz - 20 kHz

TECHNICAL SPECIFICATIONS

System type 2-way vented enclosure
High Frequency Device1 “ dome tweeter on elliptical waveguide
Low Frequency Device8” woofer with fiberglass reinforced cone
Angular Coverage 90° H x 60° V
HF Amplifier Continuous Power20W Class AB
LF Amplifier Continuous Power70W Class AB
Processing Analog
Frequency Response45 Hz - 20 kHz
Max SPL 109 dB
Connectors 1/4” JACK, XLR-F, RCA
Controls LEVEL, HF ADJUST
Construction Vinyl laminated MDF cabinet with ABS front
Cabinet Colour Black
Power Supply 230 VAC or 120 VAC 50/60 Hz with LINE VOLTAGE selector
Dimensions (W x H x D)265 x 380 x 305 mm
Weight 10 kg
